SmartyCam 3 Compatibility: Hyundai i20 N Rally2

SmartyCam 3 GP Compatibility With Hyundai i20 N Rally2

Equipped with a heavy-duty bullet camera, the SmartyCam 3 GP has been specifically designed to withstand extreme motorsport environments. By integrating directly to the Hyundai i20 N Rally2’s ECU through its CAN system, the SmartyCam 3 GP can overlay critical performance data—such as speed, RPM and gear position—directly onto HD video footage in real time. Key features of the SmartyCam 3 GP include:

• Automatic start/stop: The camera automatically begins recording when the engine is turned on/off, ensuring no data is missed.
• Bullet camera: With additional mounting solutions, the compact, external bullet camera can be mounted in tight spaces or outside the car if desired.
• Robust design: With its IP65-rated waterproof body, the SmartyCam 3 GP can withstand harsh rally conditions.
• Plug & play installation: The cables and harnesses in the kit match the i20 N Rally2’s loom, eliminating the need for complex rewiring. This ensures quick and secure installation that won’t interfere with the car’s existing electronics.
• Telemetry integration: Overlays critical performance data directly over the footage, making it ideal for post-session analysis.

The CAN driver developed to communicate with the Hyundai i20 N Rally2 (from 2021) is accessible through the Main_24Camera connector, a Deutsch DTM06-6P connector located on the central tunnel next to the fuel tank wall.

Important: When connecting an Aim device to the vehicle CAN bus, check if the promoter and the federation regulations allow the use of a GPS module to be connected at the same time.

For this installation, please refer to the following pinout:

Technical note: Please select the proper power supply according to the Aim device in use. The SmartyCam has Vb pin 3 used for wake-up and Vbext pin 5 used for power supply.

Channels received by Aim devices configured with Hyundai i20 N Rally2 protocol are:

Remember: Not all data channels outlined in the ECU template are validated for each manufacturer’s model or variant; some of the outlined channels are model and year-specific, and therefore may not be applicable.

SmartyCam 3 Dual Compatibility With Hyundai i20 N Rally2

Much like the SmartyCam 3 GP, the bullet cameras are compact and can be mounted in various locations of the i20 N Rally2. However, the SmartyCam 3 Dual takes video analysis one step further by allowing drivers and teams to simultaneously record multiple viewpoints with two bullet cameras. As the most versative camera in the series, here are just some of the SmartyCam 3 Dual’s key features that can enhance the Hyundai i20 N Rally2’s data collection:

• Automatic start/stop: The camera automatically begins recording when the engine is turned on/off, ensuring no data is missed.
• Bullet camera design: With additional mounting solutions, the compact, external bullet camera can be mounted in tight spaces or outside the car if desired.
• Dual perspectives: Records views of both the road and the cockpit that synchronises with the car’s data for a comprehensive understanding of vehicle dynamics and driver actions.
• Plug & play installation: The cables and harnesses in the kit match the Hyundai’s loom, eliminating the need for complex rewiring. This ensures quick and secure installation that won’t interfere with the car’s existing electronics.
• Seamless ECU integration: Overlays critical performance data—such as speed, RPM and gear position—directly onto video footage in real time, making it ideal for post-session analysis.
• Robust construction: Built to withstand the rigours of rally racing, including exposure to dust, vibrations and varying temperatures.

The CAN driver developed to communicate with the Hyundai i20 N Rally2 (from 2021) is accessible through the Main_24Camera connector, a Deutsch DTM06-6P connector located on the central tunnel next to the fuel tank wall. By connecting to the CAN network, the SmartyCam 3 Dual can access real time data from the car’s ECU. This data can be overlaid onto the video footage, offering a synchronised display of performance parameters alongside the video recording.

Important: When connecting an Aim device to the vehicle CAN bus, check if the promoter and the federation regulations allow the use of a GPS module to be connected at the same time.

For this installation, please refer to the following pinout:

Technical note: Please select the proper power supply according to the Aim device in use. The SmartyCam has Vb pin 3 used for wake-up and Vbext pin 5 used for power supply.

Channels received by Aim devices configured with Hyundai i20 N Rally2 protocol are:

Remember: Not all data channels outlined in the ECU template are validated for each manufacturer’s model or variant; some of the outlined channels are model and year-specific, and therefore may not be applicable.

Why Choose A SmartyCam 3 For The Hyundai i20 N Rally2?

When integrated into the i20 N Rally2’s electrical systems, Aim SmartyCams each provide HD video, synchronised with performance telemetry overlays. This seamless integration helps rally car drivers and teams to analyse and optimise their performance to get the best results during competitive rally settings.

Overall, all three cameras are designed to withstand the rigours of motorsport environments and offer customisable data overlays to suit specific analysis requirements. To learn more about how each camera can be integrated into your Hyundai i20 N Rally2’s setup, please visit the following pages:

• Hyundai i20 N Rally2 Aim SmartyCam 3 Corsa Kit
• Hyundai i20 N Rally2 Aim SmartyCam 3 GP Kit
• Hyundai i20 N Rally2 Aim SmartyCam 3 Dual Kit
