Solo 2
Solo 2 DL
Model
Overview
Aim Technologies Solo 2 Lap Timer samples data, predictive, theoretical and delta lap times, and has complete data recall with over 4,000 tracks on file.
Aim Technologies Solo 2 DL Lap Timer and data logger has predictive, theoretical and delta lap times, and complete data recall and download for analysis.
Key Features
- 4GB Internal Memory
- Database with over 4,000 Tracks Worldwide
- Automatic Track Recognition
- Integrated GPS
- Multiple Race Modes: Speed, Times & Performance
- Ten Configurable RGB LEDs
- Wi-fi Connectability
- Graphical Display
- Open or Closed Track Creation
- Suitable for any Motorsport Vehicle
- 4GB Internal Memory
- Database with Over 4,000 Tracks worldwide
- Automatic Track Recognition
- Integrated GPS
- Multiple Race Modes: Speed, Times & Performance
- Ten Configurable RGB LEDs
- Wi-fi Connectability
- GLONASS Receiver
- Direct ECU Data Logging
- Predictive Lap Timing
- Up to 8 Configurable Displays
- 8 Coloured Backlight Choices
- Choice of Connection
Size & Weight
- Dimensions: 98.0 x 73.7 x 30.2mm
- Weight: 240g, battery included
- Dimensions: 98.0 x 73.7 x 30.2mm
- Weight: 240g, battery included
Waterproof
- IP 65
- IP 65
In The Box
- Solo 2
- Wall Charger with AC Adaptor
- Mounting Bracket with Screws
- Aim Sticker
- Power Cable with Car Lighter Socket
- Solo 2 DL
- Wall Charger with AC Adaptor
- Mounting Bracket with Screws
- Aim Sticker
- Choice of Power Leads Available as Selected at Checkout. Only One Supplied
- User Manual
- CAN/K-Line External Power Cable with OBDII Connector
- CAN/RS232 external power cable
- RPM external power cable (if your vehicle has no ECU)
Technical
- Inertial Platform Internal 3 axis +5G accelerometer + 3 axis gyro +3 axis magnetometer
- Wi-Fi Connection: Yes
- GPS: 25 Hz
- External Power: 9-15 V
- Connectors: 1 socket (binder) 712, 5 pins
- Memory: 4 GB
- Battery Type: Rechargeable Lithium
- Pushbuttons: Metallic
- Inertial Platform Internal 3 axis +5G accelerometer + 3 axis gyro +3 axis magnetometer
- Wi-Fi Connection: Yes
- GPS: 25 Hz
- External Power: 9-15 V
- Connectors: 1 socket (binder) 712, 5 pins, 1 socket (binder) 712, 8 pins
- Memory: 4 GB
- Battery Type: Rechargeable Lithium
- Pushbuttons: Metallic
- ECU Connection: CAN, RS23 or K-Line to thousands of industry-leading ECUs
Display
- Display: Graphical LCD
- Display Resolution: 238 x 99 pixels
- Display Pages: Up to 5 freely configurable
- Backlight: 8 configurable RGB colours
- Shift Lights/Alarm LEDs: 10 configurable RGB LEDs
- Display: Graphical LCD
- Display Resolution: 238 x 99 pixels
- Display Pages: Up to 8 freely configurable
- Backlight: 8 configurable RGB colours
- Shift Lights/Alarm LEDs: 10 configurable RGB LEDs
Integrated Track Database
- Over 4,000 Worldwide
- Over 4,000 Worldwide
